Futaba S-C300 Standard Digital Servo PWM/S.BUS2 9.6kg 0.12s 4.8V - 7.4V

The Futaba S-C300 is a versatile, standard-sized digital servo designed primarily for 1/10 scale electric RC cars. Positioned as a high-value, mid-range option, it combines a durable metal gear train with the advanced features of the S.Bus2 ecosystem. One of its standout features is its compatibility with ultra-high-speed signal modes like UR (Ultra Response) and SR (Super Response), which, when paired with compatible Futaba car systems (like the T10PX or T7PXR), provides a snappier, more connected driving feel.

Key Features:

• S.Bus2 & PWM Support: Can be used with traditional PWM receivers or integrated into a digital S.Bus2 network for simplified wiring and telemetry feedback.
• High-Speed Mode Compatibility: Fully supports UR, SR, and Digital modes, making it an excellent choice for club-level racing where response time is critical.
• Metal Gear Train: Features a robust 2-3 stage metal gear design with a durable aluminum final gear to handle the rigors of off-road bashing and high-grip on-road racing.
• Programmable Logic: Using a CIU-3 interface or an S.Bus-compatible transmitter, you can customize travel, damping, and smoothness to match your specific chassis and driving style.
• 25T Spline: Uses the industry-standard 25-tooth spline (Ø6mm), ensuring compatibility with a wide range of aftermarket aluminum servo horns.

Technical Specifications:

Important Application Note:

The S-C300 is specifically optimized for car use. While it shares the "standard" footprint of aircraft servos, Futaba recommends using this model with car receivers. It is ideally suited for 1/10 scale steering duties or as a throttle/brake servo in nitro applications (though please note it is not waterproof, so a sealed radio box is recommended for wet conditions).
