Tired of charging one battery at a time? Try the PowerPal 4!

This charger allows you to plug 4 batteries into one charger simultaneously, and it will intelligently and automatically charge all 4 of them at once to their maximum capacity. To top it off, the batteries being charged do not even need to be the same type or configuration. You can connect different types Ni-MH/Ni-CD/LiPo/LiFe batteries into any of the charging ports. No more staying up late for charging batteries.

PowerPal 4 has a maximum output power of 200W. As a result it could charge a 15 cell NiCd/NiMH pack at 5.0A and 6 cells of Lithium batteries with a maximum current of 5.0A at the same time. Furthermore the high performance fans provide an extremely efficient cooling system.

It can store data for 5 different batteries per charge output (20 in total). Input power monitoring when using a 12v car battery source will avoid any damage by ending the charge automatically if the voltage drops below the required minimum.

Specification:

Operating voltage range - DC 11-15V

Power Source - 12V DC(Car Battery) / AC/DC Power Supply (>200 Watts) - recommend 20-30A input for best results on 4 function use

Charge Power - 50Watts per channel, current is regulated accordingly (e.g. 11.1V battery, charge current approx. 4.5A)

Discharge Power - 5 watts, current is regulated accordingly

Cell Count - 1-15 NiCd/NiMH cells, 1-6 LiPo/LiIon/LiFe cells, 1-10 Lead acid (2-20V)

Current Drain for balancing lithium - 300mA

Charger Dimensions - 225.4 x 158.6 x 62.4mm

Net Weight - 1.09kg

Will peform 1 to 5 cycles of charge/discharge or discharge/charge.

(Please note performance and charging capability depends on power input source. To charge 4 batteries at maximum power, will require 20-30amp power supply. Alternatively a lower power source may allow 2 batteries to be charged while 2 are discharged. A poor power source will result in reduced charging performance)
